Overview
About this product
Technical Specifications
Name: Battery Pack
Capacity: 222Wh / 18.5Ah @12V/60000mAh @3.7V
266.4Wh / 22.2Ah @ 12V / 72000mAh @ 3.7V
DC Input: 18-24V/ 4A(max)
TYPE-C input: DC5V/3A 9V/3A 12V/3A 15V/3A 20V/3A
Cigar Lighter Socket: 12V / 15A(max)
USB output: 5V/4.5A 4.5V/5A 9V/2A 12V/1.5A
TYPE-C output1: DC5V/3A 9V/3A 12V/3A 15V/3A 20V/3A
TYPE-C output2: DC5V/3A 9V/2A 12V/2.25A(PPS:3.3-11V/3A)
DC Laptop output: 12V/5A 16.5V/4A 20V/3.5A 24V/2A
Wireless: 10W
Size: 230*125*44mm N.W: 1500g
Two recharge ways: DC port Input/ USB-C port Input
1- Plug the adapter`s cable into the DC / type-C input port of the power bank
2- Connect the Adapter to AC 100V-240V
3- The power bank starts to charge automatically. Please see the below details:
4- Charging time: DC port supports Solar panel Max 80W charging,(It can be fully charged the power bank in 3-4 hours) Support USB-C Max 60W charging (5-6 hours can fully charged the power bank)
To charge your devices
1- Support Devices: Mobile phones, Tablet PC, Digital Camera, and other digital devices
2- Plug a USB cable into one of the Output ports
3- Connect the cable with your device
4- The power bank starts discharging automatically
Use the power bank to charge the laptop
1. Firstly choose the correct Laptop DC connector before charging your laptop
2. Keep long-press the power button until the LED screen is turned on. Then choose the right working voltage according to the laptop charging voltage. The first stage voltage is 12V, the Second is 16.5V, the third is 20V, Fourth stage is 24V. Followed By Recycling
3. Connect the laptop connector after choosing the correct voltage. The laptop starts charging
