HARDWARE FEATURES
- Interface : 3× 10/100/1000Mbps RJ45 LAN Ports,
1× 10/100/1000Mbps RJ45 WAN/LAN Port,
1× RJ11 Port,
1× USB 2.0 Port
- Ports : 3× 10/100/1000Mbps RJ45 LAN Ports,
1× 10/100/1000Mbps RJ45 WAN/LAN Port,
1× RJ11 Port,
1× USB 2.0 Port
- Button : WPS Button, Wi-Fi On/Off Button, Reset Button
- External Power Supply : 12V/1A
- IEEE Standards : IEEE 802.3, IEEE 802.3u, 802.3ab
- VDSL2 Standards : ITU G.993.2, Up to 17a profile (POTS)
ITU-T G.993.5 (G.vector)
ITU-T G.998.4 (G.INP)
- ADSL Standards : Full-rate ANSI T1.413 Issue 2,
ITU-T G.992.1(G.DMT),
ITU-T G.992.2(G.Lite),
ITU-T G.994.1 (G.hs),
- ADSL2 Standards : ITU-T G.992.3 (G.DMT.bis)
- ADSL2+ Standards : ITU-T G.992.5
- Dimensions ( W x D x H ) : 8.5 × 4.9 × 1.2 in (215.6 × 124.6 × 31.6 mm)
- Antenna Type : 2× fixed Omini-Directional antennas

WIRELESS FEATURES :
- Wireless Standards : IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz
- Frequency : 2.4 GHz and 5 GHz
- Signal Rate : 867Mbps at 5 GHz, 300Mbps at 2.4 GHz
- Wireless Functions : Enable/Disable Wireless Radio, WMM, Wireless Statistics
- Wireless Security : 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions
- Transmission Power : <20dBm (2.4 GHz), <23dBm (5 GHz)
- Wireless Schedule : Support 2.4 GHz and 5 GHz Wireless Schedule

SOFTWARE FEATURES
- Security : NAT Firewall, SPI Firewall, Access Control, Service Filtering, Denial of Service (DoS), SYN Flooding, Ping of Death, IP and MAC Address Binding
- Operating Modes : VDSL/ADSL Modem Router, Wireless Router, 3G/4G Router
- Management : Web-Based Configuration (HTTP / HTTPS ), Remote management,
Command Line Interface, SSL for TR-069, SNMP v1/2c, Firmware Upgrade, Diagnostic Tools, Free Online Firmware Update
- DHCP : Server, Client, DHCP Client List, Address Reservation, DHCP Relay
- Port Forwarding : Virtual Server, Port Triggering, DMZ, ALG, UPnP
- Dynamic DNS : DynDns, NO-IP, TP-Link
- VPN : OpenVPN, PPTP VPN, IPSec VPN
- Protocols : Supports IPv4 and IPv6
- ATM/PPP Protocols : ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364), PPP over Ethernet (RFC2516), IPoA (RFC1577/2225), MER\IPoE (RFC 1483 Routed), Bridge (RFC1483 Bridge), PVC – Up to 8 PVCs
- Advanced Features : Parental Controls, Network Address Translation(NAT), Port Mapping
(Grouping), Static Routing, RIP v1/v2 (optional), DDNS, IGMP V1/V2/V3
- Guest Network : 2.4GHz Guest Network, 5GHz Guest Network

OTHERS
- Certification : CE, RCM, RoHS
- Package Contents : AC1200 Wireless MU-MIMO VDSL/ADSL Modem Router Archer VR400
External Splitter
RJ11 DSL Cable
RJ45 Ethernet Cable
Power Adapter
Quick Installation Guide
- System Requirements : Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10, macOS, NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other
Java-enabled browser
Subscription with an internet service provider (for internet access)
